The HM-EV-T series TVR Evaporator System is a high-efficiency evaporation and concentration unit designed on the principle of vacuum low-temperature evaporation. By recycling and reusing secondary steam multiple times, it achieves significant steam energy savings. Available in configurations ranging from single-effect, double-effect, triple-effect, quadruple-effect to five-effect, the system can be tailored to meet specific evaporation capacity and energy efficiency requirements. In terms of structural design, it offers three main types: falling film, forced falling film, and forced circulation.
This versatile system is ideally suited for the evaporation of heat-sensitive, high-concentration, high-viscosity, and corrosive materials. It finds wide application across multiple industries, including: concentration of corn steeping liquid and maltose syrup in the starch & glucose industry; concentration of fruit juice and flavoring liquids in the food industry; concentration of liquid milk in the dairy industry; concentration of sugar juice in the sugar industry; and concentration of distiller's grains filtrate in the alcohol industry.
Model | Evaporation capacity | Steam consumption kg/h | Each effect vacuum, mmHg | Each effect temp. ℃ | Steam pres. | Feed DS,% | Discharge DS, % | ||||
1st effect | 2nd effect | 3rd effect | 1st effect | 2nd effect | 3rd effect | ||||||
HM-EV1.0-T | 1000.0 | 250-300 | 0.0 | 448.0 | 640.0 | 99.0 | 76.0 | 53.0 | 0.6-1.0 | 6-7 | 42-48 |
HM-EV3.0-T | 3000.0 | 750-900 | |||||||||
HM-EV4.5-T | 4500.0 | 1200-1350 | |||||||||
HM-EV6.0-T | 6000.0 | 1600-1800 | |||||||||
HM-EV9.0-T | 9000.0 | 1500-2700 | |||||||||
HM-EV12.0-T | 12000.0 | 3000-3600 | |||||||||
HM-EV15.0-T | 15000.0 | 3750-4500 | |||||||||
HM-EV20.0-T | 20000.0 | 5000-6000 | |||||||||
HM-EV25.0-T | 25000.0 | 6250-7500 | |||||||||
HM-EV30.0-T | 30000.0 | 7500-9000 | |||||||||
HM-EV50.0-T | 50000.0 | 12500-15000 | |||||||||
HM-EV-M series MVR evaporator system compress the secondary steam generated by the steam according to the principle of mechanical compression, so as to raise its temperature to a certain extent and return the heating system to replace the raw steam as the heat source of the heater, so as to make full use of the waste steam, recover the latent heat, improve the thermal efficiency, and achieve the purpose of saving steam energy. At the same time, it also reduces the demand for external cooling resources, reduces energy consumption and reduces pollution. This product is mainly used in multi - effect evaporation and crystallization equipment.
Comparison and Evaluation Table of MVR and Five-effect Evaporator:
Evaporation type | Five-effect evaporator | MVR evaporator | |
Evaporation capacity × evaporator qty. | 100tph×1set | 100tph×1set | |
Energy consumption | Steam, t/h | 27.4 | 5.56 |
Pump electricity consumption, KWH | 465 | 430 | |
MVR electricity consumption, KWH | 0 | 1890 | |
Cooling water consumption, m3/h | 1300 | 300 | |
Annual energy consumption | Steam price, RMB/ton | 180 | |
Electricity price, RMB / KWH | 0.55 | ||
Running days, days / year | 330 | ||
Annual steam consumption cost around, ten thousand RMB / year | 3900 | 790 | |
Annual power consumption cost around, ten thousand RMB / year | 200 | 1000 | |
Annual energy consumption around, ten thousand RMB / year | 4100 | 1800 | |
Main material | 304/316L | ||
The payback period for the investment of fixed assets that are overinvested due to the use of MVR evaporator | Around 230 days | ||
1) Running stably, highly efficient and energy-saving & low steam consumption.
2) High concentration ratio.
3) Low evaporation temp, suitable for the concentration of heat-sensitive materials.
4) High separation effect and greater flexible operation.
1) High thermal efficiency and energy saving
2) Intelligent control, stable running, low failure rate.
3) Easy operation and convenient maintenance
4) Compact structure and reasonable configuration
The whole system is designed reasonably and beautifully, running stably, highly efficient and energy-saving, and low steam consumption.
High concentration ratio, falling film evaporation, so that the viscosity of the material liquid easy to evaporation, and short time concentration.
Special design, realize switching efficiency through simple operation to adapt to the production of different products.
Low evaporation temp, suitable for the concentration of heat-sensitive materials.
High heat transfer coefficient and high evaporation rate, which can prevent the "dry wall" phenomenon.
High separation effect and greater flexible operation.
Compact structure, small floor area and simple & smooth layout.
In and out of the material continuously. The material liquid can reach the required concentration after passing through the equipment once.
If the material needs continuous sterilization treatment, the sterilization and concentration of two processes completed at one time. The material has short heating time and is suitable for the concentration of heat-sensitive material liquid.
Equipped with CIP cleaning pipeline. The equipment can be cleaned on the spot. The whole equipment is easy to operate without dead Angle.
The power control is realized by the control cabinet, and the automatic control system can be installed according to the user's requirements.
Special pump, reliable seal, stable performance, little maintenance and smooth operation.
