HM-SD-Q spray drying is a drying process in which the raw material solution is separated into droplets in an atomizer and the powder particle shape product is obtained by direct contact between hot air or other gases and droplets. At present, spray drying technology has been widely used in the production of maltodextrin, detergent, dairy products, dehydrated food, dye, cement and fertilizer. The most common milk powder, instant coffee, convenient food soup and other products are obtained from the spray drying process.
| Model | Drying capacity, kg/h | Feed DS, % | Discharge moisture, % | Heating type | Tower body dia., mm |
| HM-SD-Q0.10 | 100 | 45-50 | 4-6 | Steam + gas burner | 1600 |
| HM-SD-Q0.20 | 200 | 45-50 | 4-6 | 2800 | |
| HM-SD-Q0.30 | 300 | 45-50 | 4-6 | 3200 | |
| HM-SD-Q0.50 | 500 | 45-50 | 4-6 | 4000 | |
| HM-SD-Q0.70 | 700 | 45-50 | 4-6 | 4800 | |
| HM-SD-Q1.00 | 1000 | 45-50 | 4-6 | 5600 | |
| HM-SD-Q1.50 | 1500 | 45-50 | 4-6 | 6800 | |
| HM-SD-Q2.00 | 2000 | 45-50 | 4-6 | 8000 |
Fast drying speed, only a few seconds to complete
Suitable for drying heat-sensitive materials
Wide range of use: according to the characteristics of materials, it can be used for hot air drying, centrifugal granulation. Most products with very different characteristics can be produced with this machine
Because the drying process is completed in an instant, the particles of the finished product can basically maintain the spherical shape of the droplet, and the product has good dispersibility, fluidity and solubility
Simplified production process and easy operation & control. Spray drying is usually used for solutions with a solid content of less than 60%. After drying, there is no need for grinding and screening, which reduces and simplifies the production process. The particle size, loose density and moisture of the product can be adjusted by changing operating conditions within a certain range, which is convenient for control and management
In order to make the material free from pollution and extend the life of the equipment, all parts in contact with the material are made of stainless steel
